ROSON for water depths up to 1,500 m

For water depths up to 1,500 m, three types of ROSON are available:

• The compact & versatile ROSON-1D (Single Drive) with a maximal pushing force of 70 kN.
• The versatile & full force ROSON-2D (Double Drive) with a maximal pushing force of 140 kN.
• The versatile & full force ROSON-3D (Triple Drive) with a maximal pushing force of 200 kN.
• The ROSON-2D and ROSON-3D are available with SingleTwist (ST) technology as well.

The various ROSON systems come with an electric driven winch with self-tensioning for heave compensation. A CPT depth up to 50 m is feasible.
Data communication from the ROSON to deck level is achieved by a powerline connection through the umbilical. This is realized by a transducer at both ends of the umbilical. These transducers, called Icone Powerline Adapters, convert the Icone signal to a powerline signal and vice versa.


•
•
•
•
•
•
